Tungsten carbide high air pressure hammer， it is connectdrill rod match drill machine for mining or quarry.The hammer has a simple design with long life, and more efficient energy transfer, faster drilling speed, lower air and oil consumption. Our factory can to customization according your requirements.
| , RP44, RP54, RP64 Gold, RP64, RP84L, RP84 hammers |
| Hammer | RP34 | RP44 | RP54 | RP64 Gold | RP64 | RP84L | RP84 |
| Type | Part No. | Part No. | Part No. | Part No. | Part No. | Part No. | Part No. |
| Standard | 9703-03-00 | 0704-03-00 | 9705-03-00 | 9706-5-30 | 9706-05-00 | 9708-8-8 | 9708-08-00 |
| 9705-05-00 |
| Q | 9703-3-4 | 9704-3-4 | 9705-3-4 | 9706-5-34 | 9706-5-4 |
|
|
| 9705-5-4 |
| QHD |
|
| 9705-03-06 API Reg |
| 9706-05-06 API Reg |
|
|
| 9705-05-06 API Reg | 9706-05-36 API Reg |
| 9706-07-36 API IF |
| WHD |
|
| 9705-03-20(API Reg) |
|
|
|
|
| Technical data |
| Effective length | 954mm | 958mm | 1069mm | 1163mm | 1213mm | 1230mm | 1323mm |
| External diameter | 83.5mm | 98mm | 120mm | 142mm | 142mm | 160mm | 178mm |
| Extermal diameter HD |
|
| 126mm | 146mm | 146mm |
|
|
| Hammer weight | 27kg | 38kg | 57kg | 96kg | 95kg | 139kg | 158kg |
| Hammer weight HD |
|
| 67kg | 109kg |
|
|
|
| Recommended bit size | 95-105mm | 110-125mm | 134-152mm | 156-178mm | 156-178mm | 191-219mm | 203-254mm |
| Rec bit size HD hammer |
|
| 140-152mm | 165-178mm | 165-178mm |
|
|
| Rit shank | COP 34(Secoroc 35'') | IR304A | IR305R | IRQL60 | IR360 Ait. Mission SD6/53-15 | Mission SD 8/63-15 | IR380 |
| Top sub thread | 2 3/6API Reg | 2 3 /6API Reg | 2 3/6 API Reg
| 3 1/2API Reg | 3 1/2API Reg | 4 1 /2API Reg | 4 1/2API Reg |
| 3 1/2 API Reg | 3 1 /2API IF |
| Wrench flat | 65mm | 65mm | 65mm | 102mm | 102mm | 120mm | 140mm |
|
|
| 95mm |
| Wrench flat HD |
|
| 95mm |
|
|
|
|
| 102mm |
| Working Pressure | 6-25 bar(87-360 psi) | 6-25 bar(87-360 psi) | 6-25 bar(87-360 psi) | 6-30 bar(87-430 psi) | 6-25 bar(87-360 psi) | 6-25 bar(87-360 psi) | 6-25 bar(87-290 psi) |
Match high wind pressure impactor for high wind pressure drill machine impact
| Product model | Out diameter *length(mm) | Weigh(kg) | Operatin wind pressure(Mpa) | Air consumption(m3/min) | Single impact | Match hammer |
| FD340 | 92*1138 | 47 | 7 - 21.0 | 35 - 18 | 30.4 | RP105-115 |
| FD350 | 122*1254 | 90 | 7 - 21.0 | 65 - 21 | 65.1 | RP138-155 |
| FD360 | 136*1450 | 126 | 7 - 21.0 | 85 - 25 | 82.2 | RP165-185 |
| FD380 | 181*1613 | 203 | 7 - 24.1 | 86 - 32.6 | 92.2 | RP190-210 |
