The Tungsten Carbide R-type Thread DTH Hammer,designed for use with roadway liquid trolleys.Tungsten carbide T-type thread DTH hammer mainly suitable for heavy-duty outdoor high-pressur drilling rigs, offers exceptional costperformance. This drill features a high-quality steel body and is embedded withthe YK05 grade alloy part. In cases where specific requirements are needed fora similar hammer, such as reinforced hammer body, special shale, or enlargedalloy parts, customization is available to meet the client's specifications.
R-type Hammer Parameter
| Model | Diameter | Thread |
| 45-R25/R32 | 45 | R25,R32 |
| 48-R25/R32 | 48 | R25,R32 |
| 51-R32 | 51 | R32 |
| 57-R32 | 57 | R32 |
| 64-R32 | 65 | R32 |
| 70-R25/R32 | 70 | R32,R38 |
| 76-R38 | 76 | R38 |
| Can be produced according to customer requirements |
T-type Hammer Parameter
| Model | Diameter | Thread |
| 76-T38 | 76 | T38 |
| 76-T45 | 76 | T45 |
| 76-T51 | 76 | T51 |
| 89-T38 | 89 | T38 |
| 89-T45 | 89 | T45 |
| 102-T45 | 102 | T45 |
| 102-T51 | 102 | T51 |
| 115-T45 | 115 | T45 |
| 115-T51 | 115 | T51 |
| 127-T51 | 127 | T51 |
| Can be produced according to customer requirements |
